Enduro · 2026
RS 500 R
Leave the road behind.
501 ccDisplacement
23.5 kWMax. power
960 mmSeat height
Colour:Black / Red
Price on request
Overview
Born for the trail: a 21-inch front wheel, generous ground clearance and a liquid-cooled single-cylinder engine — SWM's Italian off-road heritage.
Specifications
RS 500 R
Engine
| Engine type | Single-cylinder, 4-stroke, liquid-cooled, spark-ignition |
|---|---|
| Displacement | 501 cc |
| Max. power | 23.5 kW @ 7500 rpm |
| Power (hp) | 32 hp |
| Starting system | Electric |
Chassis & brakes
| Front brake | Disc Ø260 mm |
|---|---|
| Rear brake | Disc Ø240 mm |
| Front tyre | 90/90-21 |
| Rear tyre | 140/80-18 |
Dimensions & weight
| Length | 2310 mm |
|---|---|
| Width | 825 mm |
| Height | 1270 mm |
| Wheelbase | 1510 mm |
| Seat height | 960 mm |
| Min. ground clearance | 310 mm |
| Fuel tank | 7.2 L |
Specifications are indicative and may change without notice. Equipment and colours may vary by market.
